Allwinner H3 Cortex-A7 Quad-Core

CPU	Allwinner H3, Quad-core ARM Cortex-A7
GPU	Mali-400 MP2 GPU @ 600MHz
Graphics API	OpenGL ES 2.0
Memory (RAM)	1GB DDR3 (Shared with GPU)
Onboard Storage	TF Card Slot (Up to 32GB)
	8GB eMMC Flash
Ethernet	10/100Mbps Ethernet RJ45
Wireless Network	Onboard Wi-Fi
Operating Systems	Android, Ubuntu, Debian, etc.
Compatibility	Raspberry Pi Compatible

Product Specification:

Item	Specification
CPU	Allwinner H3, Quad-core ARM Cortex-A7
GPU	Mali-400 MP2 GPU @ 600MHz
Graphics API	OpenGL ES 2.0
Memory (RAM)	1GB DDR3 (Shared with GPU)
Onboard Storage	TF Card Slot (Up to 32GB)
	8GB eMMC Flash
Ethernet	10/100Mbps Ethernet (RJ45)
Wireless Network	Onboard Wi-Fi
Video Input	CSI Camera Interface
Video Output	HDMI, CVBS
Audio Input	Microphone (MIC)
Audio Output	3.5mm Audio Jack, HDMI Audio
Power Supply	DC Input
	Micro-USB (OTG) Not supported for power input
USB Interfaces	3 × USB 2.0 Host
	1 × USB 2.0 OTG
Low-Level Peripherals	40-pin Header, Raspberry Pi Compatible
Debug Interface	UART-TX, UART-RX, GND
LED Indicators	Power LED, Status LED
Buttons	Power Button (SW4)
Operating Systems	Android, Ubuntu, Debian, etc.
Dimensions	85mm × 55mm
Weight	43g
